Rated Power Supply V

220-240 V

Rated Frequency Hz

50

Rated Washing Capacity kg

10

Rated Spinning Capacity kg

10

Rated drying Capacity kg

7

Rated Power W

1900

Rated Current A

10

Max. Spin Speed RPM

1500

Standard Water Pressure Mpa

0.05～1 Mpa

Display Type

LED

Display Color

White

Door Lock

Electromagnetic Lock

Motor

BLDC Motor

Plug type

Euro Plug

Power cord length mm

1.5

Water Inlet Hose Length mm

1

Water Outlet Hose Length mm

1.6

Energy efficiency class(Old)

A

Energy efficiency class for the complete wash cycle(New)

B

Energy efficiency class for the complete wash & dry cycle(New)

D

Spin-drying effiency class

B

Moisture Ratio

0.53

Washing efficiency index

1.04

Energy efficiency index for the complete wash cycle

60

Energy efficiency index for the complete wash & dry cycle

67

Power consumption left-on mode W

1

Power consumption off-mode W

0.5

Weighted energy consumption per 100 cycles for the complete wash cycle kW·h/100 cycles

59

Weighted energy consumption per 100 cycles for the complete wash & dry cycle kW·h/100 cycles

343

Energy consumption in kWh per cycle for the complete wash cycle kW·h/cycle

0.593

Energy consumption in kWh per cycle for the complete wash & dry cycle kW·h/cycle

3.43

Weighted water consumption per cycle for the complete wash cycle L/cycle

52

Weighted water consumption per cycle for the complete wash & dry cycle L/cycle

100

Program duration at rated capacity for the complete wash cycle min

239

Program duration at rated capacity for the complete wash & dry cycle min

580

Spinning noise level dB

80

Spinning noise class

C

 My Cycle

yes

 20℃

yes

 Intensive

yes

 ECO 40-60

yes

 Wool

yes

 Drum Clean

yes

 Baby Care

yes

 Spin Only

yes

 Rinse&Spin

yes

 Dry Only

yes

 Quick 15'/1hr WD

yes

 Mix

yes

 Wash and Dry

yes

 Cotton

yes

 Delay

yes （24 hours）

 Temp

yes

 Speed

yes

 SpaCare

yes

 Dry

less-standard-extra-time dry

 Functions

yes

 Speed Wash

yes

 Extra Rinse

yes

 Prewash

yes

 Mute-washing(Press 3 seconds)

yes

 Memory (Press 3 seconds)

yes

 Child Lock (Combined)

yes

 Reload (Press 3 seconds)

yes

 Spin Speed Selection

0-400-600-800-1000-1200-1400-1500

 Temperature Selection

Cold-20℃-30℃-40℃-60℃-90℃

Volume Of Inner Tub L

70

Diameter Of Inner Tub mm

510

Door Diameter mm

330

Door Outer Frame Diameter (outer) mm

480

Net Dimensions (W×D×H) mm

595 × 565 × 850

Gross Dimensions (W×D×H) mm

680 × 695× 875

Net Weight kg

72

Gross Weight kg

76

 20 ft

48

 40 ft Normal

102

 40 ft High

153

CBM (m³)

0.413525
