Evvoli Portable Air Conditioner | 1.0 Ton | 12000 BTU
Evvoli Portable Air Conditioner | 1.0 Ton | 12000 BTU
Share
Collapsible content
Beat the heat anywhere, anytime! Engineered for ultimate comfort, this 12,000BTU Portable AC comes with a complete suite of practical features to keep you cool and comfortable, day and night.
Customizable Airflow: Experience personalized comfort with no-drip technology, a 24-hour timer, and rolling wheels equipped with auto-oscillation. Tailor the airflow effortlessly to your exact needs and comfort level.
Effortless Installation and 3-in-1 Standby Mode: Enjoy hassle-free setup and seamless operation with easy installation and versatile 3-in-1 standby mode.
Golden Fin: This special coating on condenser coils protects against corrosion, ensures efficient heat exchange for faster cooling and energy savings, and maintains long-term performance in harsh conditions. It also contributes to cleaner indoor air quality by inhibiting microbial growth.
Low-Noise Operation and Energy Efficiency: Powered by a T3 rotary compressor and utilizing R410A refrigerant, this unit delivers highly efficient cooling while operating quietly. Stay cool without disturbing your surroundings.
Whether it's for your home, office, warehouse, or small business, the Evvoli Portable Air Conditioner ensures reliable cooling wherever you need it. Stay cool, comfortable, and in control, no matter how high the mercury climbs.
Power SupplyPower supply V,Hz,Ph 220-240V,1Ph Cooling (T1)Capacity Btu/h 12000 Input W 1350 Current A 5.87 EER W/W 2.60 Cooling (T3)Capacity Btu/h 12000 Input W 1350 Current A 5.87 EER W/W 2.60 HeatingCapacity Btu/h 10000 Input W 1130 Current A 4.91 COP W/W 2.60 Moisture RemovalMoisture Removal L/h 1.2 Rated input consumptionRated input consumption W 1540 Rated currentRated current A 8 Starting currentStarting current A 25 CompressorModel ASM125V1VDZ Type Rotary Brand GMCC Capacity Btu/h 3590/3625 Input W 845/895 Rated current(RLA) A 3.85/3.75 Locked rotor Amp(LRA) A 25.0 Thermal protector / Thermal protector position INTERNAL Capacitor uF 35.0 Refrigerant oil ml ESTER OIL VG74/350 CBMTTL m3 0.201674 |
Indoor Side Fan MotorModel YKT-18-6-209L-2 Input W 52.0 Capacitor uF 1.5 Speed(hi/mi/lo) r/min 760/690/650 Indoor CoilNumber of rows 3 Tube pitch(a)x row pitch(b) mm 21x13.37 Fin spacing mm 1.2 Fin type (code) Hydrophilic aluminum Tube outside dia.and type mm Φ7Inner groove tube Coil length x height x width mm 322x294x40.11 Number of circuits 2 Indoor Air Flow / Noise LevelIndoor side air flow(Hi) m3/h 425/380/360 Indoor side sound pressure level (Hi/Mi/Lo) dB(A) 52.5/51.5/51.0 Outdoor CoilNumber of rows 4 Tube pitch(a)x row pitch(b) mm 14.5*12.56 Fin spacing mm 1.2 Fin type (code) UnHydrophilic aluminium Tube outside dia.and type mm Φ5innergroove tube Coil length x height x width mm 265*50.24*319 Number of circuits 2 Outdoor Side Fan MotorModel YKT-50-4-222L Input W 117 Capacitor uF 3 Speed(hi/mi/lo) r/min 1020/660 RefrigerantType R410A Charged quantity kg 0.43 SpecificationDesign pressure MPa 1.5/4.2 Plug type 1.5x3/VDE Control type Remote Control Operation temp (room temp.) ℃ 17-35 Application area (Coolling Standard) m2 16-23 Dimension (W*D*H) mm 467x397x765 Packing (W*D*H) mm 515x440x890 Net/Gross weight Kg 33.74/37.46 Container LoadingQty’per 20’ /40’ /40'HQ Pieces 114/238/353 |
Evvoli UAE Store:
Shop 5, Ground Floor, Car Parking Building - Souk Deira St - Dubai
UAE Contact Details:
Customer Service: +971 58 253 1800
Showroom: +971 4 250 0066
Monday to Saturday, 09:00 am - 06:00 pm
Email: support@evvoli.ae
Glad you love our product!
To ensure you get the best out of it, here is your comprehensive user manual. Inside, you'll find
essential safety information, detailed product specifications, easy installation and operation
guides, cleaning and maintenance tips, a troubleshooting guide, warranty details, and more!
Everything you need for safe and optimal use is just a click away:
